FIX Level Anti-Vibration Levelers

Maximum Stability and Vibration Reduction for Your Applications

FIX Level anti-vibration levelers can be configured with an anti-vibration surface to provide stable and optimized support, even in industrial environments characterized by significant vibrations. This advanced solution is designed to enhance machine longevity and minimize the impact of vibrations on overall performance.

Key Technical Specifications:
Base Material: Air Loc – Type SL
Profile: Double, on two sides
Permitted Loads: From 4 daN/cm² to 12 daN/cm² (approximately 4 kg/cm² – 12 kg/cm²)
Optimal Load: 10 daN/cm² (approximately 10 kg/cm²)
Overlay Thickness: 7 mm
Color: Green
Adhesion Coefficient to Concrete: 0.80
Natural Frequency (Hz):
- Vertical: 95 (at medium load)
- Horizontal: 30 (at medium load)
Temperature Range: 0 °C to 70 °C

Benefits of FIX Level Anti-Vibration Levelers:
Vibration Reduction: Improves efficiency and extends machine lifespan.
Optimal Stability: Ensures reliable support even under challenging operational conditions.
Versatile Applications: Compatible with a wide range of industrial uses
