FLS Series Leveling Element

Livellatori FIX LEVEL FLS _ AMU Princigalli

FLS Levelers: Lightweight and High Performance

FLS levelers are the perfect solution for those seeking a simplified and lighter version of the FL Standard Series.
Thanks to an innovative design, we have developed a lighter leveler while maintaining load capacity and elasticity modulus unchanged.

Tested at the renowned OMECO Research and Testing Institute in Monza, FLS levelers ensure reliability and high performance for all stability requirements.

Available Models:
- FLS III
Designed for axial static loads up to 3,000 kg.
- FLS IV
Ideal for axial static loads up to 5,000 kg.

Both models offer a safety margin six times greater than the maximum indicated static load, ensuring uncompromised stability and durability.

Determining the Fix Level Model

The recommended load, proportional to the machine, is calculated by dividing the machine's net weight by the number of support points.
In cases of significant weight disparity between different sections of the machine, the weight of the heaviest section must be considered and divided by the number of support points.
The resulting dimension serves as the reference value for the support to be placed under the machine.

Catalog:
Customizable Options for Fix Level Levelers

Customize your levelers for every requirement.
With Fix Level levelers, you can choose from various options to achieve the ideal configuration, perfectly tailored to your technical and operational needs.

Benefits of Customizable Options:

- Maximum flexibility for diverse applications.
- Modular configurations tailored to your needs.
- Uncompromising quality and reliability.

Download the complete catalog to explore all available options and find the perfect solution for your project.
